SETUP WORKING WIDTH | CR7 | QUICKSTART STEERING MANUAL
PAGE 8/34 | User manual | 016-8000-017EN | Rev. B
In case there are more sections, configure
the sections. In case of just one section, the
section is always the same as the Total Width
(generated automatically).
Press next step.
Enter the value from the rear axle to the
reference point of the implement (for
example where the seed hits the ground).
Press next step.
If the implement is not in the center of the
machine, enter the offset.
If it is in the center, leave this on 0.
Press the green checkmark.
Select Mount Equipment to add more
implements (enter all the machines that are
going to be used with GPS Autosteer).
