24
7) GPS OPTIONS
A) GPS is inactive when the RATE display shows "GPS" and the DATA display shows
"InAC".
The GPS features are explained further in the GRID APPLICATION SYSTEM
MANUAL.
B) Momentarily depress
to advance to FIELD REFERENCE.
8) FIELD REFERENCE
A) RATE display will show "FrEF". DATA display will show "0".
B) Enter the field number.
C) Momentarily depress
to advance to BAUD RATE.
9) BAUD RATE
A) RATE display will show "bAUd". DATA display will show "1200".
B) Depressing
momentarily changes the DATA display between "1200" and
"9600".
C) Momentarily depress
to advance to DATA LOGGER TRIGGER VALUE.
10) DATA LOGGER TRIGGER VALUE
A) RATE display will show "TriG". DATA display will show "0".
B) Enter the TRIGGER VALUE.
C) Momentarily depress to advance to DATA LOGGER TRIGGER UNITS.
NOTE: The TRIGGER VALUE default value is "zero". This value must be changed
to a desired number ranging from 1-9999. The DATA LOGGER features will
not work if this number is not changed.
11) DATA LOGGER TRIGGER UNITS
A) RATE display will show "UniT". DATA display will show "FT"["nETr"].
B) Depressing
momentarily changes the DATA display between "FT" [nETr"]
and "SEC". A value of "FT"["nETr"] means feet [meters], or a value of "SEC"
means seconds have been chosen as the unit of measurement for the TRIGGER
VALUE programmed previously.
C) Momentarily depress
to advance to DATA LOGGER.
To Next Page
