25
12) DATA LOGGER ON/OFF
A) The DATA LOGGER uses the communications strings listed in Appendix 9 to pass
data out through the serial port. The data is sent at a set time interval
or a set distance traveled, as determined by the values entered in the DATA
LOGGER TRIGGER VALUE and DATA LOGGER TRIGGER UNITS. Upon each trigger, the
Actual Rate string, Data Strings 1, 2, and 3, and the Time/date string are
sent, in that order. When a Console calibration value is changed, the
Console will automatically send out the Cal 1, 2, and 3 strings. When a
Console switch is changed, the Data 1, 2, 3, Time/Date, and Cal 1, 2, 3
strings will be sent by the Console. The Data, (with Time/Date string
included) and Cal strings can also be requested by the data logger using
the request strings shown in Appendix 9.
B) RATE display will show "dLOG". DATA display will show "oFF".
C) Depressing momentarily changes the DATA display between "oFF" and
"on". A value of "oFF" means DATA LOGGER is disabled; a value of "on" means
DATA LOGGER is enabled.
D) Momentarily depress
to advance to CONSOLE DATA PRINTOUT.
NOTE: Some options within the DATA MENU LISTINGS may be unavailable if certain
features are on or active. The options affected are:
CONSOLE DATA PRINTOUT: Console Data Printout will not be available when DATA
LOGGER is ON or when GPS functions are ACTIVE.
GPS OPTIONS: GPS Options will not be available when DATA LOGGER is
ON.
DATA LOGGER: DATA LOGGER will not be available when GPS functions
are active.
