Raven SCS 4600 Operator's Manual

17
NOTE: If an entry selection error is made during steps 1-6, turn console power OFF.
Depress and hold while turning console power ON.
Display will show Initial Contrast Adjustment. Use key to lighten or key to darken contrast.
Press when done.
1) Display ACRE-US, HECTARE-SI, or TURF-SQ FEET.
a) Depressing momentarily steps the display from ACRE-US to HECTARE-SI.
b) Depressing momentarily steps the display from HECTARE-SI to TURF-SQ FEET.
c) Depressing momentarily steps the display from TURF-SQ FEET to ACRE-US.
2) Selecting ACRE, HECTARE, or TURF
a) To select ACRE, HECTARE, or TURF, step until the desired code is displayed.
b) Momentarily depress , the display will now display LIQUID.
3) Display LIQUID (liquid sprayer), GRAN 1 (single belt bed), GRAN 2 (split belt bed) or GRAN 3
(split belt bed, dual encoders).
a) Depressing momentarily steps the display from LIQUID to GRAN 1.
b) Depressing momentarily steps the display from GRAN 1 to GRAN 2.
c) Depressing momentarily steps the display from GRAN 2 to GRAN 3.
d) Depressing momentarily steps the display from GRAN 3 to LIQUID.
4) Selecting LIQUID, GRAN 1, GRAN 2, or GRAN 3.
a) To select product control, step until desired code is displayed.
b) Momentarily depress , the display will now display STD VALVE.
5) Display AIM COMMAND, FAST VALVE, FST CLS VALVE, PWM VALVE, or PWM CLS VALVE.
a) Depressing momentarily steps the display from AIM COMMAND to FAST VALVE.
b) Depressing momentarily steps the display from FAST VALVE to FST CLS VALVE.
c) Depressing momentarily steps the display from FST CLS VALVE to PWM VALVE.
d) Depressing momentarily steps the display from PWM VALVE to PWM CLS VALVE.
e) Depressing momentarily steps the display from PWM CLS VALVE to AIM
COMMAND.
