User Guide
RFL-C2000S-HP /RFL-C3000S-HP /RFL-C4000S-HP/RFL-C6000S-HP
32
Table 12 Description of laser working status display
Emergency
Red - indicates that the emergency stop button on the front panel of the laser is
pressed
Gray - Indicates that the emergency stop button on the front panel of the laser has
been reset
C3000S-C4000S-C6000S HP don’t have this function
REM
Green - the laser works in REM mode
Gray - the laser works in ON mode
C3000S-C4000S-C6000S HP don’t have this function
Laser Enable
Green - the laser is enabled
Gray - the laser not enabled
Fiber Interlock
Green - The Interlock on output cable head is connected
Gray - The Interlock on the output cable head is disconnected
Interlock1
Green - pins 1 and 4 on the control interface are connected
Gray - pins 1 and 4 on the control interface are disconnected
Interlock2
Green - pins 2 and 3 on the control interface are connected
Gray - pins 2 and 3 on the control interface are disconnected
Interlock Logic
Green - Interlock1& 2 meet logic requirements
Gray - Interlock1& 2 do not meet logical requirements
Program Mode
Green - The laser is running in programming mode
Gray - The laser is not running in programming mode
Ramp Control
Green - the laser is running in power ramp-up and ramp-down mode
Gray - the laser is not running in power ramp-down mode
Programexecut
Program is executing
Programcomplete
Program execution complete
Programexception
Abnormal program execution
Table 13 Description of Control Area Icons
Main Power
Click ON, the main power is power on
Click OFF, the main power is power off
Guide Laser
Click ON, turn on the red guide beam
Click OFF, turn off the red guide beam
Guide Laser External Control
Click ON, turn on the 17-pin red guide beam control function
Click OFF, turn off the 17-pin red guide beam control function
Mode power off automatic memory
External Enable
Click ON,turn on the 18-pin enable function
Click OFF, turn off the 18-pin enable function
Mode power off automatic memory
Analog Control
Click ON, turn on the AD analog mode
Click OFF, turn off the AD analog mode
Mode power off automatic memory
External Emission
Click ON, turn on the 15-pin laser control function
Click OFF, turn off the 15-pin laser control function
Reset
Clear the alarm of the current laser
Emission ON
Emit laser
Emission OFF
No emit laser
