Wuhan Raycus Fiber Laser Technologies Co., Ltd.
User Guide of RFL-C6000S-CE
14
3 Installation
3.1 Dimensions
Figure 2 shows dimensions of RFL-C6000S-CE.
Figure 2a) Frontand Rear panel view(unit: mm)
Figure 2b) Top and Side view(unit: mm)
