Wuhan Raycus Fiber Laser Technologies Co., Ltd.
User Guide of RFL-C6000S-CE
20
4 Using the Product
Please use the correct the latest PC software and the relevant
manual.
4.1 Front Panel
Figure 6 shows the front panel of RFL-C6000S-CE：
Figure 6 Front Panel of RFL-C6000S-CE
a) POWER:Control system power indicator light, when the red light is on, it means that
the laser is powered on.
b) LASER:The laser is emitting light normally. When the green light is on, it means that
the laser is emitting light.
c) ALARM:Alarm indication, when the yellow light is on, it means that the machine
has an alarm.
4.2 Rear Panel
Figure 7 shows the rear panel of RFL-C6000S-CE:
Figure 7 Rear Panel of RFL-C6000S-CE
