Wuhan Raycus Fiber Laser Technologies Co., Ltd.
User Guide of RFL-C6000S-CE
40
q) Shortconnect the 8 and 9 pins on the INTERFACE 24 pins (the control board is powered
on);
r) Open the laser clientware;
s) Click “the guide laser ON” button to view the guide laser;
t) Open the AD mode, the external enable, the external modulation mode;
u) On Click on the main power ON;
v) Waiting “Ready”;
w) Interface 24 stitches on 18 pin input rising edges;
x) When the internal output frequency occupation ratio of the laser is required, set out the light
frequency/duty cycle/pulse width; (out of the output of the light and the output of the output
of the 15.16 -pin and the output ratio of the upper machine software); no internal output
inside the laser is required When the frequency occupation ratio, the default setting
parameter is 100Hz and the duty cycle is 100%.
y) Control board card output analog (12, 14 pin) and outlet signals (15, 16 pin).
4.8.2.6 Modification mode and Gate mode
Modification mode: When the duty cycle of the internal frequency of the laser is set to
100%, the laser works in the external modulation mode.
Gate mode: When the duty occupation ratio of the internal frequency of the laser is less than
100%, the laser works in the internal modulation mode. Stop the internal pulse occurring;
4.9 Guide laser control
Table10 Guide laser control
17 pin of INTERFACE
Rising edge -- turns on guide laser;
Fallingedge -- turns on guide laser.
The clientware
：
Red ON -- turns ON guide laser;
Red OFF -- Turns OFF guide laser.
