Wuhan Raycus Fiber Laser Technologies Co., Ltd.
User Guide of RFL-C6000S-CE
52
Figure41 The homepage of the clientware
If any alarm occurs (except for Interlock alarm)when the laser is running, the clientware will
display the alarm that occurs, and the ALARM light (yellow) on the front panel of the laser will
light up, the laser will stop emitting and lock.
When the Interlock is abnormal, the output of Ready signal is low, and the Interlock state is
abnormal in the clientware, but the laser is not locked, and the ALARM light (yellow) is not lit.
Theoutput of Ready signal is on high level when the Interlock is normal.
5.2 Alarm solutions
The instructions and solutionsof alarms are as follows:
Table 12 Instructions and solutionsfor alarms of laser
Alarm instructions and solutions
Instruction:
Low temperature/high temperature alarm of the laser. The sensor in the laser
detects an abnormal temperature inside the laser. A high-temperature /
low-temperature error occurs when the temperature at the monitoring point
exceeds the set upper / lower limit.
Solution:
High temperature alarm,please check if the water-cooling system is normally
working, the water temperature is set correctly, and the water connection is
correct. When the water cooling system works normally and the water
temperature drops below 30°C, restart the laser.
To Next Page
