Raycus RFL-C6000X User Manual

Wuhan Raycus Fiber Laser Technologies Co., Ltd.
User Guide of RFL-C3300W~RFL-C15000W
8
Weight (kg)
<250
<280
<360
<400
<450
<500
<800
Air
conditioning
included
Operating
Ambient
Temperature
(°C)
10～40
/
Humidity(%
)
＜70
/
Storage
temperature
(°C)
-10
～
60
/
Cooling
method
Water cooling
/
3 Installation
3.1 Dimensions
The mechanical appearance dimensions of RFLC3300X/ C4000X/ C6000X/
C8000X/ C10000X/ C12000X/ C15000 continuous wave fiber laser are as follow:
(1) The external dimensions of the RFL-C3300X/ C4000X continuous wave fiber
laser are shown in Figure 1 (taking RFL-C3300X as an example).
Figure 1-a Front and rear view of the laser.
