Wuhan Raycus Fiber Laser Technologies Co., Ltd.
User Guide of RFL-C3300W~RFL-C15000W
22
The circuit breaker which is located on the side panel is the power switch of
the device, as shown in Figure 9.
4.3 Power Connection
CAUTION:
(1) Before connect the product to AC power, you must check up
that the AC supply you will apply is in accordance with the
specifications provided in Table 1.
(2) Failure to correctly connect the cable could damage the
device. Please check whether the power cable and the
control cable is correctly connected before usage.
A power cord is provided in the package, as in Figure 10:
a) 3.3kW / 4kW power cord. b) 6kW / 8kW / 10kW / 12kW power cord. c)
15kW power cord.
Figure 10 The Power Cord of the Laser.
The end of the power cord is a plug; insert it into the socket ‘AC INPUT’ on
the rear panel when using the laser. Notice that the plug is wrong-side preventing.
After insert it, lock it with the lock. As shown in Figure11.
