Wuhan Raycus Fiber Laser Technologies Co., Ltd.
User Guide of RFL-C3300W~RFL-C15000W
23
a) The picture of 3.3kW / 4kW power port plug / socket.
b) The picture of 6kW / 8kW/ 10kW/ 12kW power port plug / socket.
c) The picture of 15kW power port plug / socket.
Figure 11 The Picture of power cord plug and socket.
Plug
Socket
Lock
Plug
Socket
Lock
Lock
Socket
Plug
