Raycus RFL-C6000X User Manual

Wuhan Raycus Fiber Laser Technologies Co., Ltd.
User Guide of RFL-C3300W~RFL-C15000W
5
Please double check if each listed contents is inside the package; and contact
Raycus as soon as possible if there is any issues.
Take extra care when removing the unit from the package to make the fiber
optic cable stay away from collision and vibration. Please do NOT distort,bend or
pull the output cable when unpacking the device; and avoid any collision to the
head of laser output.
CAUTION: The fiber optic cable and output head are precise
optic instrument, ANY vibration or impact to the output head, and
twist or excessive bend to the cable will damage the instrument.
2.4 Operation Environment
The operation conditions are listed as the following table:
Table 1: The Operation Environment Conditions for the Laser
Model
C3300X
C4000X
C6000X
C8000X
C10000X
C12000X
C15000
Supply voltage (V)
Three-phase four-wire systemAC 323V~AC 437V
、
50/60Hz (including PE)
Power supply
capacity (kVA)
>20
>25
>40
>50
>65
>80
>95
Water cooling flow
(L/min)
>33
>43
>50
>60
>75
>90
>112
Installation
Environment
Flat, no vibration nor impact
Ambient
Temperature
10
℃
~40
℃
Relative Humidity
≤70%
(1) Make sure the product is properly grounded before use.
(2) The laser output head is connected with fiber optic cable. Please inspect the
output head carefully for dust or other contaminations. Use appropriate lens
paper to clean it if necessary.
(3) Failure to follow the instructions when operating the laser may cause
malfunction and damage.
(4) It is not allowed to install the output head when the laser is in operation.
