 Interlock interface must not be connected to active signal, otherwise it
will cause interface damage and laser alarm.
4.4.2 TCP/IP Interface Configuration
Thedefault IP address of this product is 192.168.0.10, only supporting UDP communication.
The laser listens for connection on port is 8098, and the command must be sent in a single data
string.
Table 8 The pin definitions of Ethernet interface
PIN
FUNCTION
DESCRIPTION
1
TX+
TRANSMIT+
2
TX-
TRANSMIT-
3
RX+
RECEIVE+
4
N/C
NONE
5
N/C
NONE
6
RX-
RECEIVE-
7
N/C
NONE
8
N/C
NONE
For better communication stability, recommend to use this interface first.
Table 9 The default IP address of the laser
The default IP address of the laser
IP address
192.168.0.10
Subnet mask
255.255.255.0
Steps of Ethernet connection:
a) Open “Local Connection” on your computer, and then click “property”;
b) Configure TCP/IP, select "Use the following IP address:";
c) Click the “Property”;
d) Check “Use the following IP address:” to manually assign an IP address;
e) Manually assign an IP address is 192.168.0. x（x cannot be 10, because 192.168.0.10
has been assigned to the laser）, and assign a subnet mask address. The default is
255.255.255.0;
