Raycus RFL-C6600S - REM Mode Operations

Wuhan Raycus Fiber Laser Technologies Co., Ltd.
User Guide of RFL- RFL-C6600S
35
4.8 Control Modes
The laser has two control modes, namely ON mode and REM mode. The user can select the
mode to enter through the key ON the front panel.In ON mode, you can only set the power
percentage, control the light output and light off.In REM mode, you can select AD mode, enable
external control, internal modulation mode, and external modulation mode.
4.8.1 REM mode
Table 10 AD mode
AD mode
Laser power
ON
12, 14 pin analog voltage 0~10V
0V——0%
10——100%
OFF
The host computer sets the power percentage.
Table 11 External enabled
External enabled
Laser enablement.
ON
18, 21 foot rising edge.
OFF
External modulation and internal
modulation OFF.
It is automatically enabled after the main
power is powered on.
External modulation or internal
modulation ON.
The laser enable button in the upper computer
software.
Table 12 External and internal modulation
External modulation
Internal modulation
Laser
ON
OFF
15, 16 pin voltage
H—The laser emission
L—Laser shut down
OFF
ON
15, 16 pin voltage
Rising edge - start the upper computer set the frequency
and pulse width of the pulse laser emission
Falling edge -- turns off the pulsed laser
OFF
OFF
The laser emission button of clientware
ON -- laser emission
OFF -- turns OFF the laser
ON
ON
null
4.8.2 The wiring diagram
