4.9 Guide laser control
"Guide laser external control" can be selected in both ON and REM modes.
Table 13 Guide laser external control
Guide laser external control
ON
17 pin
Rising edge -- turns on guide laser;
Fallingedge -- turns on guide laser.
OFF
The clientware：
Red ON -- turns ON guide laser;
Red OFF -- Turns OFF guide laser.
4.10 The Programming Mode (Waveform Editing)
4.10.1 The Programming Mode enable method
In the Programming Mode, the laser has the functions of waveform editing, storing and
calling.The Programming Mode can be used in the external modulation mode in both ON and
REM modes.
Note: The Programming Mode function is used in REM mode, only the external modulation
mode can be selected, and the internal modulation mode cannot be selected.
Table 14 The Programming Mode enable method
Programming Mode
The laser is determined by the edit waveform
Open: The current program
number is not 0.
ON mode
Laser ON -- Start the program to execute
Laser OFF -- Terminate the program
External
modulated modes
in REM mode
INTERFACE24 pin 15, 16 pin voltage:
Rising time -- Start the program to execute
Falling time -- Terminates program running
Close: The current program
number is 0
Do not execute a programming program
When the current program number of the laser is not 0, the laser runs in Program
Mode.Please use the software of Raycus to edit the waveform, and select the program number of
pre-run. The output waveform of laser is determined by the edited waveform. Under the
