Raymarine G-Series system User Manual

G-Series Installation & Commissioning 103
Appendix ATechnical specification
GPM400 Processor module
GPM400 Processor module
Nominal supply
voltage
12 V / 24 VDC
Operating voltage
range
10.7 V to 32 V DC
Fuse / Breakers 12 V supply:
10 A fuse protection at distribution panel
10 A thermal circuit breaker protection at distribution
panel
24 V supply:
4 A fuse protection at distribution panel
5 A thermal circuit breaker protection at distribution
panel
Typical Power
consumption
No external loads
3 A @ 12 V
1.5 A @ 24 V
With external loads
5 A @ 12 V
2.5 A @ 24 V
Environmental
conditions:
operating temperature: -15°C to 55°C (5°F to 131°F)
non-operating temperature: -25°C to 70°C (-13°F to
158°F)
relative humidity limit: 80%
water protection: drip resistant when mounted
vertically
Storage conditions for
packaged unit:
Temperature: -25°C to 55°C (-13°F to 158°F)
relative humidity: 75%
Dimensions: Width = 335 mm (13.19 in)
Height =230 mm (9.06 in)
Depth = 125 mm (4.92 in),
Weight 6.5 kg (14.33 lb)
Data connections NMEA 0183 (x2)
SeaTalk
SeaTalk
ng
SeaTalk
hs
Compact flash
USB (software upgrade only)
Video DVI x 2
(Optional VGA adaptor available)
Audio Stereo line out (rated 1 V rms)
SeaTalk / alarm power
output
250 mA at 12 V
CE approvals -
conforms to:
89/336/EEC as amended by 92/31/EEC,
EN60945:2002
