93 Chapter 9: Troubleshooting
Keyboards
The keyboard does not operate monitor setting
menus.
On or more monitors are not listed when config-
uring the monitors or Nav Stations.
SeaTalk
hs
network problem Check the status of the SeaTalk
hs
Switch.
Refer to troubleshooting SeaTalk
hs
Switch LED indica-
tions on page 98
Check the marine monitor and ensure that the network
selector switch is in the “up” position (required when
connected to the SeaTalk
hs
network).
Check that the monitor and GPM400 are both connected
to the SeaTalk
hs
switch.
Check that SeaTalk
hs
cables are free from damage.
The monitor is not a Raymarine G-Series unit. Only G-Series marine monitors are compatible with the
SeaTalk
hs
network required for this functionality.
Software mismatch between equipment may
prevent communication.
Contact Raymarine technical support
Problem Possible causes Possible solutions
Problem Possible causes Possible solutions
Keyboard LCD is blank.
(Monitor may also show no keyboards
connected message)
The Keyboard is not connected to SeaTalk
ng
or
has no power.
Check keyboard wiring and power to SeaTalk
ng
bus.
Wireless keyboard is not charged up. Connect wireless keyboard to charge point.
Keyboard LCD shows low battery Wireless keyboard battery requires charging
Degraded / old keyboard battery requires
replacing
Charge keyboard battery at appropriate charge point.
Replace battery
Keyboard LCD shows sw version message.
e.g 86/78 F64D V0.6A
(Monitor may also show no keyboards
connected message)
The Keyboard cannot communicate with a
GPM400 processor
Ensure GPM400 processors are connected to the
SeaTalk
ng
system.
Wireless basestation is not operating or is
disconnected from SeaTalk
ng
.
Check power and connections to SeaTalk
ng
wireless
basestation.
Wireless basestation is out of range Re-survey wireless coverage and move / add repeat
basestations if necessary.
