43 Chapter 4: Cables and connections
See also
Ensure you record connections to the GPM400 on the schematic
diagram. See Appendix B - Nav Station schematic .
4.6 Video and Entertainment
Video and entertainment is connected and distributed to the
G-Series system using 2 system components:
• GVM400 Video Module
•SeaTalk
hs
switch.
Note: Video equipment may also be connected directly into the
displays, although this will not be distributed around the
system.
5 m (16.4 ft)
SeaTalk
ng
spur cable
A06041
Wireless basestation to SeaTalk
ng
1 m (3.3 ft)
SeaTalk
ng
spur cable
(bare ends)
A06043 Included with wireless
basestation.
3 m (9.8 ft)
SeaTalk
ng
spur cable
(bare ends)
A06044
Dashboard / Charging
2.5 m (8.2 ft)
charging cable
R08311 Included with the wireless
upgrade kit.
3 m (9.8 ft)
SeaTalk
ng
bulkhead
mounting cable
R08310
See Appendix C for other cables and accessories.
