G-Series Installation & Commissioning 44
Typical video system
Maximum quantity of GVM400 video modules
The G-Series system will support up to 2 GVM400 video modules.
D10076-1
SeaTalk
hs
switch
S-Video and Audio
SeaTalk
hs
SeaTalk
hs
SeaTalk
hs
network
DVD
OR
Sat
TV
GVM400 video module
Composite
Composite
Composite
