Raymarine G-Series system User Manual

G-Series Installation & Commissioning 100
GVM400 LED indications
DSM400 LED indications
Color Operation Causes
Normal operation
Green Flashing
(various rates, depending upon system data)
• Normal operation
Warnings and Errors
Amber On steady • Power on
•Lamp test
Amber Flashing x 1 • Acquisition failure
Amber Flashing x 2 • No network / cable unplugged
Amber Flashing x 3 • Other network error
Amber/Red Alternating 750/250 ms • Software upgrade. This condition remains until a valid application is available
from Flash
Red Flashing x 1 • Unit can no longer poll input status
Red Flashing x 4 • Flash write error
Red Flashing x 6 • Video stopped
Red Flashing x 7 • Video error
Red Flashing x 8
(May be followed by Flashing amber)
• Hardware read failure
Color Operation Causes
Normal operation
Green Flashing 500 / 500 ms • Normal operation (Heartbeat)
Green Flashing 750 / 250ms • Standby mode
