ST80 Maxiview Operation and Setup
33
• The dead reckoned screen is displayed providing data is available.
• Fields where data is not available appear as dashes.
• The elapsed time is displayed in minutes and seconds.
• The displayed bearing and range is to the man in the water.
Lat/Lon MOB
D2543-1
maxiview
remote
08:30
Press this key momentarily
to display dead reckoned
information if available.
MOB POS
078
TRUE
1.2 NM
• This screen is displayed upon entry to MOB if dead reckoned
information is not available.
• Time data may not be shown if the man-overboard data is not
sourced from ST80.
Incomplete MOB Data
If there is insufficient data to provide range, bearing and elapsed
time, the following screen is displayed during an MOB condition.
D2544-1
maxiview
remote
MAN
OVER
BOARD
