Chapter 3: Installation
21
D4819-1
5
Screw stud into instrument
5 Fit instrument
D4817-1
6
Feed cables through clamping bracket,
connect cables then secure instrument with
bracket and thumb nut
Desktop Mounting Bracket
An optional Desktop Mounting Bracket (Part No. E25024) enables you
to mount your ST40 instrument in locations where other forms of
mounting are impractical.
