18 - READ OUT FLOW CHART
Simbol Description
Push RESET button
Push and hold for at least 2 seconds the reset button
Push and hold for at least 5 seconds the reset button
Push and hold together for a time in seconds explained by the number the RESET button and button
Push button
Push button
Parameters
shown during
normal operations
(See Section
14.15)
User’s menu
parameters
(see Section
14.13)
Gain access to users’
menu (see Section
14.13)
Gain access to installers’
menu (see Section
14.14)
Exit from users’ menu
Exit from installers’ menu
Where:
Installers’
menu
parameters
(see Section
14.14)
Changing
of the
parameters’
value
