RD Instruments WorkHorse Sentinel - Figure 1. Sentinel ADCP Overview

WorkHorse Sentinel User's Guide
P/N 957-6163-00 (January 2001) page 5
URETHANE FACE
BEAM 3 MARK
THERMISTOR
PRESSURE SENSOR
(OPTIONAL)
TRANSDUCER
HEAD
HOUSING
MEMORY CARD
INTERNAL BATTERY
PACK
END-CAP
I/O CABLE
CONNECTOR
Figure 1. Sentinel ADCP Overview
