RDS PS 8000 User Manual

1.6.5 The INFO screen page
Additional work measurement functions are displayed on this page. If only one tank is
enabled, the screen will display only the product selected and not the tank number as
shown in figure 6.
NOTE: If more than one tank is enabled there is a separate screen page for each tank (as for
the MAIN screen). Press the INFO menu key repeatedly to cycle between each
page.
1.6.6 The LOG screen page (Apollo only)
This page controls data logging (Field Summary data), and P.F. functions (when the
Data Card Module is connected and enabled) and data transfer (e.g. printing a job
summary).
1 - Overview
Figure 6
The INFO screen
In/Out of work indication
(Area accumulation)
Amount sprayed
Area Accumulated
RPM indicator
e.g. for Fan, PTO,
or Engine depending
on the installation
Tank / Product
Reset PART or
NORMAL Totals
Select Tank-filling options
Select PART or
NORMAL Total
display
Select and review / clear / print
summary data for stored jobs
Start/end logging
Figure 7
The LOG screen
Select GPS Status
screen
Check Alarm
Condition
10
