B.3 Class Detect, dual signature mode
RT-PoE commands:
PSE check after commands issued
reset
detect ok
single off
class 0
connect on
Verify that the PSE sees a legacy class 0 PD.
connect off
class 1
connect on
Verify that the PSE sees a compliant class 1 PD.
connect off
class 1L
connect on
Verify that the PSE sees a legacy class 1 PD.
connect off
class 5
connect on
Verify that the PSE sees a compliant class 5 PD.
connect off
class aon
set xxx
connect on
Verify that the PSE is able to detect autoclass
capability, and support a load of xxx mA.
