Reach PoE5 Tester Manual 1.8 03/25/2021 Page 8
3. Configuration Guide
3.1. Power
The power input is located on the rear of the unit. The power supply provided is a
"desktop" type brick with a three-prong IEC input connector. There is no power switch; it
is on when the power is applied.
Order an optional accessory kit to get a six-foot AC power cord with an IEC 320 C13
connector with a mating outlet type to match your region.
3.2. Serial Console
The serial console port is located at the rear of the unit. It is an RJ-45 with a three-wire
RS-232 level interface. The interface has the same pinout as found on Cisco routers and
switches. The baud rate factory default is 115200, 1 stop, no parity, 8 bits. The baud rate
can be changed by software command see the BAUD command in the Command
Reference section. Characters are echoed as they are typed (full duplex).
Order an optional accessory kit to get a console cable with either a DB9 or USB
connection.
RJ-45 Connector:
Pin
Signal (DTE name)
1
**
2
**
3
RS-232 data output (TxD)
4
Ground
5
Ground
6
RS-232 data input (RxD)
7
**
8
**
** these signals are connected to each other
