Reach RT-PoE5 - Class Detect, Single Signature Mode

Reach PoE5 Tester Manual 1.8 03/25/2021 Page 38
B.4 Class Detect, single signature mode
RT-PoE commands:
PSE check after commands issued
reset
detect ok
single on
mps 1
class 0
connect on
Verify that the PSE sees a class 0 PD.
connect off
class 1
connect on
Verify that the PSE sees a class 1 PD.
connect off
class 2
connect on
Verify that the PSE sees a class 2 PD.
connect off
class 3
connect on
Verify that the PSE sees a class 3 PD.
connect off
class 4
connect on
Verify that the PSE sees a class 4 PD.
connect off
class 5
connect on
Verify that the PSE sees a class 5 PD.
connect off
class 6
connect on
Verify that the PSE sees a class 6 PD.
connect off
class 7
connect on
Verify that the PSE sees a class 7 PD.
connect off
class 8
connect on
Verify that the PSE sees a class 8 PD.
connect off
class aon
set yyy
connect on
Verify that the PSE is able to detect autoclass
capability, and support a load of yyy mA.
