B.5 Power Status and overload (IEEE 802.3af)
RT-PoE commands:
PSE check after commands issued
reset
detect ok
class 3
set 20
connect on
Enable power to port
Verify that PSE sees the device taking power.
status
Verify that power is on.
getv
Verify that voltages are as expected.
set 350
Verify that PSE is providing full power.
set 390
Verify that PSE sees overload and shuts off
power.
status
Verify that power is off.
B.6 Power Status and overload (IEEE 802.3at)
Same as above, but use “class 4”, and “set 600” for full power and “set 660” for overload.
