10
6. Stand & Wheelkit Assembly - Cont.
Fitting the Bandsaw to the Stand
1. Lift the bandsaw over the stand. and place the long
fixing bolts through the four location holes in the
bandsaw base.
2. Secure the bandsaw to the stand with the remaining
washers and nuts.
CAUTION!
The machine is heavy. Additional help or a suitable
lifting device or support will be required for lifting the
machine onto the stand.
Fitting the Wheelkit Handle to
the Bandsaw
Secure the wheelkit handle in position on the rear of the
bandsaw column buy using the two hex nuts and washers.
Note
When fitting the bandsaw to the stand, ensure
that the wheels are positioned at the front of the
bandsaw, i.e. below the table of the bandsaw.
