6. Stand & Wheelkit Assembly
Stand & Wheel Kit Assembly
The stand and wheel kit comes as a self assembly unit.
Stand
A. Upper Frame
B. Long mid brace supports x2
C. Short mid brace supports x2
D. Legs x4
Stand fixing nuts bolts and washers (each) x22
WheelKit
E. Hex bolt x8
F. Fixed wheels x2
G. Tubular handle
H. Bolts and washers x2
CAUTION! The machine is heavy. Additional help or
a suitable lifting device or support will be required for
lifting the machine onto the stand.
E
7
F
H
A
B
C
D
G
