11
Unpacking and Components Included
The machine is supplied partly assembled. Prior to use,
further assembly is required.
When unpacking the machine the following components
are included for the initial assembly
A. M6 Nuts x2 and small crank handle
Table Assembly
B. Table
C. Table fixing bolts and washers x4 (each)
D. Table levelling nut and bolt
E. Wing nuts x4
F. Rip fence carrier with scale
G. Rip fence
7. Machine Assembly
A
B
C
D
F
G
E
