16. Parts Lists & Diagrams - Cont.
1 SBS12-1 Hexagon socket cap head screw 2
2 SBS12-2 Spacer bush 2
3 SBS12-3 Hx. Hd. Lock nut 2
4 SBS12-4 Lower door assembly 1
5 SBS12-5 Leaf spring-rear lock 2
6 SBS12-6 Rivet 4
7 SBS12-7 Upper door assembly 1
8 SBS12-8 Band saw tyre 2
9 SBS12-9 Hexagon socket cap head screw 3
10 SBS12-10 Spring washer 3
11 SBS12-11 Lower band wheel 1
12 SBS12-12 Pulley for lower band wheel 1
13 SBS12-13 Deep groove ball bearing 4
14 SBS12-14 Hexagon nut 1
15 SBS12-15 Blade (*Various options available) 1
16 SBS12-16 Spring washer 1
17 SBS12-17 Upper band wheel 1
18 SBS12-18 Spring washer 1
19 SBS12-19 Deep groove ball bearing 2
20 SBS12-20 Tension wheel 1
21 SBS12-21 Sliding shaft 1
22 SBS12-22 Cup square neck bolt 1
23 SBS12-23 Brush assembly 1
24 SBS12-24 Spacer bush 1
25 SBS12-25 Cross pan head screw 2
26 SBS12-26 NVR switch with emergency
stop cover
1
27 SBS12-27 Upper wheel shaft 1
28 SBS12-28 Wheel carrier bracket 1
29 SBS12-29 C Ring 2
30 SBS12-30 Parallel pin 1
31 SBS12-31 Tension bracket frame 1
32 SBS12-32 Disc spring set 24
33 SBS12-33 Shaft 1
34 SBS12-34 Nut 1
35 SBS12-35 Tension bracket 1
36 SBS12-36 Guide Roller 3
37 SBS12-37 Shaft for pilot 1
38 SBS12-38 Knurled thumb screw 2
39 SBS12-39 Hexagonal screw 2
40 SBS12-40 Parallel pin 1
41 SBS12-41 Roller guide housing 1
42 SBS12-42 Pilot block 2
43 SBS12-43 Shaft for gear 1
44 SBS12-44 Pan head tapping screw 2
45 SBS12-45 Sliding board 1
46 SBS12-46 Roller guide seat 1
47 SBS12-47 Guide carrier extrusion 1
48 SBS12-48 Rack 1
49 SBS12-49 Cover board 1
50 SBS12-50 Serrated washer 2
51 SBS12-51 Pan head tapping screw 2
52 SBS12-52 Door locking knob 2
53 SBS12-53 Washer 2
54 SBS12-54 Hexagon socket cap head screw 2
55 SBS12-55 Adjusting knob 1
56 SBS12-56 Compressor spring 1
57 SBS12-57 Locking Knob 1
58 SBS12-58 Cable & plug assembly 1
59 SBS12-59 Motor cable 1
60 SBS12-60 Tension knob 1
61 SBS12-61 Hexagon nut 2
62 SBS12-62 Tensioning shaft 1
63 SBS12-63 Plastic end cap for column 1
64 SBS12-64 Adjusting knob 1
65 SBS12-65 Hexagon bolt 1
66 SBS12-66 Wing Nut 2
67 SBS12-67 Idler wheel shaft 1
68 SBS12-68 Hexagon flange nut 1
69 SBS12-69 Hx. Hd. Lock nut 1
70 SBS12-70 Washer 1
71 SBS12-71 Hexagonal screw 2
72 SBS12-72 Pilot pin 2
73 SBS12-73 Deep groove ball bearing 1
74 SBS12-74 Lower guiding piece pad 1
75 SBS12-75 Lower wheel shaft 1
76 SBS12-76 Motor 1
77 SBS12-77 Suction connector 1
78 SBS12-78 Crank handle 1
79 SBS12-79 Hexagon nut 12
No. Part Number Part Name Quantity No. Part Number Part Name Quantity
