Troubleshooting
26 Owner’s Guide – Redback Smart Hybrid System – v3.8
LED
NAME
COLOUR &
PATTERN
MEANING AND OR
PROBABLE CAUSE
SOLUTION(S)
BACKUP
POWER
Backup is ready

OK. No action required: battery power is available for the backup circuit.
This response may take up to 10 minutes after a restart.
Backup is off / no
power available
Contact your installer.
BATTERY
Battery is charging

OK.
No action required.
Contact your installer if this is unexpected behaviour.
Battery is discharging
Battery is below
“Minimum SoC”
setting
Wait for the battery to charge to a value above the Minimum SoC. Contact
your installer if the indication persists.
Batteries not active
Ensure BATTERY SYSTEM DC isolator is ON (up).
SYSTEM
ERROR
Ground fault alarm.
An audible alarm will be heard, indicating the Ground Fault has continued
for more than one minute. The fault is confirmed by notifications on email
and the Redback portal.
Contact your installer as soon as possible.
Other error
(no audible alarm).
Wait 10 minutes. System errors may be caused by temporary external
factors, such as grid power quality, and may resolve without intervention.
If the error does not resolve within 10 minutes, restart the inverter (9.4).
If the error does not resolve following a restart:
• Move the Bypass switch to the UP position- this maintains continuous
grid supply to the backup circuit. Note: backup function will be halted.
• Contact your installer as soon as possible.
Backup circuit
overload (exceeds
4.6kW continuous or
6.9kW for 10s, at
<45°C)
Reduce simultaneous plug-in loads on the backup circuit. Contact your
installer if overloads persist.
Ensure plug-in devices on the backup circuit are in accordance with section
8.5.
No fault

OK. No action required.
COMMUNICATIONS
The Communications LED is controlled by the EMS. If the EMS is not operational, the LED will remain
in the last known state.
Online

OK. Connected to the Redback cloud. No action required.
Cannot connect to the
Redback cloud
Internet connection lost. Ensure the local network is operating correctly.
Onboarding required.
BT available.
Inverter is Bluetooth (BT) discoverable. Connect your phone to begin
onboarding.
Bluetooth connection established. Continue onboarding.
Onboarding required.
BT timed out
Restart Bluetooth. Set the Bypass switch to the middle position for 5
seconds then return to the original position.
Bluetooth times out after 30 minutes of inactivity.
No active comm’s
(local network not
connected)
Ensure the local network is operating correctly.
Changes to router or passwords will require re-onboarding.
If communications do not re-establish, restart the EMS (section 9.3).
If communications do not re-establish within 10 minutes of a EMS restart, re-
onboard the inverter (section 11).
LEGEND:
OFF
ON
Flashing
Double Flash
