Redback SH5000 - Specifications

Specifications
32 Owner’s Guide – Redback Smart Hybrid System – v3.8
Specifications
PV PORT
Version 022x
Version 024x
Number of MPPTs
2
2
Strings per MPPT Input
1/1
1/1
MPPT Operating Voltage (range)
DC 125 - 550V
DC 125 - 550V
MPPT Full Load (range)
DC 215 – 500V
DC 190 – 500V
Maximum Input Voltage (Vmax)
DC 580V
DC 580V
Maximum Current (Imp)
DC 11/11A
DC 14/14A
Short Circuit Current (Isc)
DC 13.8/13.8A
DC 17.5.17.5A
Maximum Feedback Current
0A
0A
Decisive Voltage Class (DVC)
DVC-C
DVC-C
GRID INTERACTIVE PORT
All versions
Nominal Output Voltage
AC 230V
Nominal Output Frequency
50 Hz
Rated Output Current
AC 24.5A
Max. Output Current
AC 24.5A
Rated Output Active Power
AC 5000W
Rated Output Apparent Power
5000VA
Rated Input Current
AC 40A
Rated Input Apparent Power
9200VA
Power Factor (range)
0.8 lagging to 0.8 leading
Output Voltage THD
<4.5%
Inrush Current
60A
,
3 µs
Maximum Output Fault Current
43A
,
0.2s
Maximum Output Overcurrent Protection
60A
,
3 µs
Decisive Voltage Class (DVC)
DVC-C
BACKUP PORT
Nominal Output Voltage
AC 230V
Nominal Output Frequency
50 Hz
Rated Current
AC 20A
Rated Active Power
AC 4600W
Rated Apparent Power
4600VA
Peak Apparent Power
6900VA (10 sec max)
Power Factor (range)
0.8 lagging to 0.8 leading
Output Voltage THD
<4.5%
Inrush Current
55A, 2µs
Maximum Output Fault Current
43A, 10s
Maximum Output Overcurrent Protection
30A
Decisive Voltage Class (DVC)
DVC-C
BATTERY PORT
Voltage (nominal)
DC 40 - 60V
Max. Current (charge)
DC 90 A
Max. Power (charge)
DC 4600W
Max. Current (discharge)
DC 100A
Max. Power (charge)
DC 4600W
Battery Type
Li-ion
Battery Depth of Discharge
90%
Short Circuit Current
1600A
Decisive Voltage Class (DVC)
DVC-A
