Specifications
34 Owner’s Guide – Redback Smart Hybrid System – v3.8
ISOLATORS
PV PORT
GRID
INTERACTIVE
PORT
BACKUP
PORT
BATTERY
PORT
BATTERY
CABINET
Manufacturer Part Number
XBE+3410/2
S201M-C40
S201-C25
NDB1-125
NDB1-125
Rated Insulation Voltage
1100V
440V
440V
500V
500V
Rated Impulse Withstand Voltage
8kV
4kV
4kV
4kV
4kV
Suitability for Isolation
C
C
C
C
C
Rated Operational Current
16A
32A
25A
125A
125A
Utilisation Category
DC-PV2
A
A
A
A
Rated Short-time Withstand Current (Icw)
700A
NA
NA
NA
NA
Rated Short-circuit Making Capacity (Icm)
1000A
NA
NA
NA
NA
Rated Breaking Capacity (Isc)
5kA
15kA
10kA
10kA
10kA
COMMUNICATIONS PORTS AND PROTOCOLS
Ethernet
RJ45; Straight-thru
DRED
RJ45; DRED
Relays
RJ45; 4x Digital I/O; +DC5V & GND
kWh Meter
RJ45; RS485 MODBUS
RS485
RJ45; Factory Use Only
WiFi
802.11b/g/n/ac; 2.4GHz
LTE
NA
Interlock
NA
USER INTERFACE
Front Panel Display
Coded, coloured LEDs
Communications
Bluetooth for commissioning; Wi-Fi or ethernet for remote access
Remote access
Web Portal or MYRedback app (Android or iOS)
Remote Firmware Updates
Supported
Power/energy monitoring
Includes 1 x utility grade energy meter (class 1)
CERTIFICATIONS, STANDARDS AND APPROVALS
AS/NZS 4777.2:2020
IEC 62116:2014
IEC 60529
RCM
IEC 62109-1:2010
EC 62040-1:2017
EN 61000
CE Mark (LVD, EMC, RoHS directives)
IEC62109-2:2011
IEC 62477-1:2012
DESIGNED WITH INSTALLATION STANDARDS CONSIDERED
AS/NZS 3000:2018
AS/NZS 5139:2019
AS/NZS 5033:2014 (inc. Amd 1 & 2)
