REDEX SRP0 - Oil Filling; Recommended Lubricants; Lubrication

SRP User manual
Ref.: RX182/006
Version 01/2017 - English
This document must not be reproduced nor information therein disclosed without our authorization
Page 4 / 28
3 LUBRICATION
3.1 Recommended lubricants
WARNING!
SRP units are delivered with oil and lubricated for a life time of 10000 hours.
Any damage to the unit due to an improper lubrication, quantity or quality, will void the
warranty.
We recommend using a synthetic PAO based oil with viscosity 150 Cst at 40°C to lubricate the SRP such
as one of the followings (or an equivalent); for alternates, please consult us.
Trade mark
Oil reference
KLUBER
KLUBERSYNTH EG4-150
MOBIL
MOBILGEAR SHC XMP 150 or
MOBIL SHC629 (warning: life time 7500 hours)
TOTAL
CARTER SH150
SHELL
OMALA HD150
LUBCON
TURMOSYNTHOIL 150
3.2 Oil filling
1. Unscrew the oil fill-in plug situated on the upper side of the unit.
2. Fill the unit until oil comes out of the level hole (approximated oil quantity is given in the following
tables).
3. Replace the oil fill-in plug.
3.2.1 SRP.M: in-line configuration
Approximated volume of oil (cm3) depending of
mounting position
B5
V1
V3
SRP0
1 stage
100
165
165
SRP1
1 stage
165
320
240
2 stages
190
350
300
SRP2
1 stage
530
1100
900
2 stages
600
1200
1123
SRP3
2 stages
1200
2100
1700
SRP4
2 stages
1450
3100
3000
SRP5
2 stages
3400
6300
6600
SRP6
2 stages
6600
11850
12750
3.2.2 SRP.R: right angle configuration
Check that the oil level reaches the middle of the sight-glass. Please note that the level on the sight glass
may take some time to stabilize.
