32 8540573 • 16/09/2016 • Rev.20
CONFIGURATION AND OPERATION MODES J LR M12
The JANUS J LR M12 operation mode is selected realizing appropriate connections on the M12
8 poles of the active element (Table 15 and Table 16).
AUTOMATICO MODE
In this operation mode the OSSD1 and OSSD2 safety outputs follow the barrier status :
with proteceted area clear, the safety outputs are active.
with proteceted area intercepted, the safety outputs are disabled.
