TECHNICAL DATA
GENERAL DATA
Safety category
4
Response time
ms
 30
Reset
automatic or manual selectable
Power supply
Vdc
24  20%
Connections
Emitter M12 – 5 pins (male)
Receiver M12 – 8 pins (male)
Receiver M23 – 19 pins (male)
* Muting sensors M12 – 5 pins (female)
Protection rating
IP 65
Max. length of
electrical connections
m
100
Dimensions light curtain section
mm
50 x 60
Operating temperature
°C
-10  55
Max operative humidity
%
95
Safety outputs
2 PNP auto-controlled – 500 mA @ 24 Vdc
with short-circuit, overload, reversal of polarity protection
Max. output current
mA
500
Max. capacitive load
F
2,2
Max. off-state voltage
V
< 1
Max. resistance of connections between
OSSDs and the loads
Ohm
< 25
Light curtain status and
weak signal outputs
PNP – 100 mA at 24 Vdc
Max. consumption
W
3 (Emitter)
6 (Receiver)
* Max current to Muting sensors
(only MI models)
mA
100
* Muting lamp output
24Vdc / 0,5  5 W
* Response time on
Muting signals (sensors)
ms
100
* Muting max. time-out models ML -
ML S2 - MT - MI with 2 sensors
30 sec or 90 min (selectable)
* Muting max. time-out
models MI with 4 sensors - MT S4
30 sec or excludible (selectable)
* Override max. time-out
min
15 (renewable)
Light curtain lifetime
20 years
Safety level
Type 4
IEC 61496-1:2004
IEC 61496-2:2006
SIL 3
IEC 61508:1998
SILCL 3
IEC 62061:2005
PL e - Cat.4
ISO 13849-1 : 2006
* Specifications applicable only to models with Muting function
MI SERIES
Heights of guarded areas
mm
310 ÷ 1810 for light curtains with a resolution of 40 and 90 mm
310 ÷ 1210 for light curtains with a resolution of 30 mm
Resolution of light curtains for
detecting upper or lower limbs
mm
30 – 40 - 90
Number of beams of light curtains for
detection of body in access control
2 – 3 – 4
Operating range Low / High
m
0 ÷ 6 / 1 ÷ 16
Muting system
two-way with 2 or 4 sensors with max. concurrent time of 4 sec
two-way sequential with 4 sensors
Muting sensors
external with relay or PNP output
