Reer JANUS - TECHNICAL DATA; General Data Specifications

36 8540573 • 16/09/2016 • Rev.20
JANUS "ML S2" - "MT S4"
Figure 35
Figure 36 - Fastening brackets LL
Figure 37 - Fastening inserts FI
Dimension
ML S2 / MT S4
D
370
E
334
F
84
(Present on MT S4
models only)
