Reer MOSAIC M1S User Manual

MODULAR SAFETY INTEGRATED CONTROLLER MOSAIC
16 8540780 • 25/01/2023 • Rev.43
English
PRODUCT COMPOSITION
The MOSAIC M1, MOSAIC M1S, MOSAIC M1S COM are supplied with:
• Multi-language installation sheet.
➔
NB: the rear panel MSC connector and MCM memory can be ordered separately as accessories.
The expansion units are supplied with:
• Multilingual Installation sheet.
• Rear panel MSC connector (not present in the MR2 and MR4 which are connected
via terminal blocks only).
➔
NB: to install an expansion unit (excluding relays) you will need the MSC connector supplied with
the unit plus another MSC for the connection to the MOSAIC M1, MOSAIC M1S or MOSAIC M1S
COM.
This can be ordered separately as an accessory.

Reer MOSAIC M1S Specifications

General

Brand	Reer
Model	MOSAIC M1S
Category	Controller
Language	English
