Reer MOSAIC M1S User Manual

MODULAR SAFETY INTEGRATED CONTROLLER MOSAIC
8540780 • 25/01/2023 • Rev.43 51
English
Response time MOSAIC M1S (ms)
This response times depends on the following
parameters:
1) Number of Slave modules installed
2) Number of Operators
3) Number of OSSD outputs
For the right response time refer to the one
calculated by the DSD software (see Project report)
Failure Response time MOSAIC M1S (ms)
This parameter corresponds to the response time,
with the exception of MV modules with
Encoder/Proximity interface where is 2s
Master MOSAIC M1S
12,75...14,75
+ T
Input_filter
MOSAIC M1S + 1 Slave
13,83...37,84
+ T
Input_filter
MOSAIC M1S + 2 Slaves
14,91...40,00
+ T
Input_filter
MOSAIC M1S + 3 Slaves
15,99...42,16
+ T
Input_filter
MOSAIC M1S + 4 Slaves
17,07...44,32
+ T
Input_filter
MOSAIC M1S + 5 Slaves
18,15...46,48
+ T
Input_filter
MOSAIC M1S + 6 Slaves
19,23...48,64
+ T
Input_filter
MOSAIC M1S + 7 Slaves
20,31...50,80
+ T
Input_filter
MOSAIC M1S + 8 Slaves
21,39...52,96
+ T
Input_filter
MOSAIC M1S + 9 Slaves
22,47...55,12
+ T
Input_filter
MOSAIC M1S + 10 Slaves
23,55...57,28
+ T
Input_filter
MOSAIC M1S + 11 Slaves
24,63...59,44
+ T
Input_filter
MOSAIC M1S + 12 Slaves
25,71...61,60
+ T
Input_filter
MOSAIC M1S + 13 Slaves
26,79...63,76
+ T
Input_filter
MOSAIC M1S + 14 Slaves
27,87...65,92
+ T
Input_filter
Response time MOSAIC M1S COM (ms)
This response times depends on the following
parameters:
1) Number of Slave modules installed
2) Number of Operators
3) Number of OSSD outputs
For the right response time refer to the one
calculated by the DSD software (see Project report)
Failure Response time MOSAIC M1S COM
(ms)
This parameter corresponds to the response time,
with the exception of MV modules with
Encoder/Proximity interface where is 2s
Master MOSAIC M1S COM
13,95...19.95
+ T
Input_filter
MOSAIC M1S COM + 1 Slave
15,03...40,16
+ T
Input_filter
MOSAIC M1S COM + 2 Slaves
16,11...42.32
+ T
Input_filter
MOSAIC M1S COM + 3 Slaves
17,19...44.48
+ T
Input_filter
MOSAIC M1S COM + 4 Slaves
18,27...46.64
+ T
Input_filter
MOSAIC M1S COM + 5 Slaves
19,35...48.80
+ T
Input_filter
MOSAIC M1S COM + 6 Slaves
20,43...50.96
+ T
Input_filter
MOSAIC M1S COM + 7 Slaves
21,51...53.12
+ T
Input_filter
MOSAIC M1S COM + 8 Slaves
22,59...55.28
+ T
Input_filter
MOSAIC M1S COM + 9 Slaves
23,67...57.44
+ T
Input_filter
MOSAIC M1S COM + 10 Slaves
24,75...59.60
+ T
Input_filter
MOSAIC M1S COM + 11 Slaves
25,83...61.76
+ T
Input_filter
MOSAIC M1S COM + 12 Slaves
26,91...63.92
+ T
Input_filter
MOSAIC M1S COM + 13 Slaves
27,99...66.08
+ T
Input_filter
MOSAIC M1S COM + 14 Slaves
29,07...68,24
+ T
Input_filter
MOSAIC M1, MOSAIC M1S, MOSAIC M1S COM, ->
module connection
ReeR proprietary 5-pole bus (MSC)
Connection cable cross-section
0,5...2,5 mm
2
/ AWG 12÷30 (solid/stranded)
Max length of connections
100m
Operating temperature
-10...55°C
Max surrounding air temperature
55°C (UL)
Storage temperature
-20...85°C
Relative humidity
10%...95%
Max. altitude (above sea level)
2000m
Vibration resistance (EN 61496-1 / class 5M1)
+/- 1.5mm (9...200 Hz)
Shock resistance (EN 61496 1/ class 3M4)
15 g (6 ms half-sine)
➔
T
Input_filter
= max filtering time from among those set on project inputs
(see "INPUTS" section").
Enclosure
Description
Electronic housing max 24 pole, with locking latch mounting
Enclosure material
Polyamide
Enclosure protection class
IP 20
Terminal blocks protection class
IP 2X
Fastening
Quick coupling to rail according to EN 60715
Dimensions (h x l x d)
108 x 22,5 x 114,5
108 x 45 x 114,5 (MOSAIC M1S COM)
