REPLACEMENT PARTS KITS (NOT with lifting assembly)
Kit Name
Kit Number
Contents
Standard FROG
3 (320)
Refer to FROG-3 unit serial
number for correct kit number
F-RPK-01-320
(for unit serial numbers FS-001 -
016)
F-RPK-02-320
(for unit serial numbers FS-017 -
212)
F-RPK-03-320
(for unit serial numbers FS-213
onwards)
1 x Main Lift-Eye Plug
2 x M16 Main Lift-Eye Securing Bolts
4 x M16 Washers
2 x M16 Securing Nuts
2 x M3 Split Pins
2 x Tamperproof Seals
1 x Stainless Steel Thread Lubricant
And either
For Type 1 (older) Keel Assemblies
1 x M48 Coarse (or Fine) Thread Nut
(subject to FROG-3 serial number)
1 x Roll Pin
2 x M10 X 60mm Hex Bolts
2 x M10 Nyloc Nuts
2 x M3 Split Pins
Or
For Type 2 (newer) Keel Assemblies
1 x M48 Fine Thread Keel Plate Boss
1 x M10 x 95 mm Hex Bolt
2 x M10 Plain Washers
1 x M10 Nyloc Nut
1 x M3 Split Pin
1 x Tamper Proof Seal
Arctic FROG 3s
(340)
Refer to FROG-3 unit serial
number for correct kit number
F-RPK-01-340
(for unit serial numbers FS-001 -
016)
F-RPK-02-340
(for unit serial numbers FS-017 -
212)
F-RPK-03-340
(for unit serial numbers FS-213
onwards)
1 x Main Lift-Eye Plug (M40 version)
2 x M16 Main Lift-Eye Securing Bolts
4 x M16 Washers
2 x M16 Securing Nuts
2 x M3 Split Pins
2 x Tamperproof Seals
1 x Stainless Steel Thread Lubricant
And either
For Type 1 (older) Keel Assemblies
1 x M48 Coarse (or Fine) Thread Nut (M40
version) (subject to FROG-3 serial number)
1 x Roll Pin
2 x M10 X 60 mm Hex Bolts
2 x M10 Nyloc Nuts
2 x M3 Split Pins
Or
For Type 2 (newer) Keel Assemblies
1 x M48 Fine Thread Keel Plate Boss (M40
version)
1 x M10 x 95 mm Hex Bolt
2 x M10 Plain Washers
1 x M10 Nyloc Nut
1 x M3 Split Pin
1 x Tamperproof Seal
