LIFTING SLING ASSEMBLY PARTS KITS
Kit Name
Kit Number
Contents
Standard FROG
3 (320) – 30ft
Lifting Assembly
Kit
220-30-A
1 x 30 ft (9 m) Sling Set Assembly c/w
2 x Shackles
1 x Sling Cover (red)
1 x Anti Fouling Bracket
1 x Shackle Spacer
4 x Heavy Duty Cable Ties
Arctic Frog 3
(340) - 30 ft.
Sling Set Kit
240-30-A
1 x 30 ft (9 m) Sling Set Assembly c/w
2 x Shackles
1 x Sling Cover (yellow)
1 x Anti Fouling Bracket
1 x Shackle Spacer
4 x Heavy Duty Cable Ties
OTHER SERVICE KITS
Kit Name
Kit Number
Contents
Back-Up Lift-Eye
Refurbishment
Kit
F-BEK-01
(all unit serial numbers)
1 x Back-Up Lift-Eye
1 x M24 Nut
1 x 3 mm x 50 mm Split Pin
1 x Tamper Proof Seal
Landing Feet Kit
(320 & 340)
Standard and
Arctic
F-LFK-320
(all unit serial numbers)
3 x Feet (foam)
3 x M20 x 200 mm Hex bolts
3 x M20 Hex Nyloc Nut
6 x M20 Plain Washer
3 x Nylon Cone Washer
Landing Feet Kit
(370) Tropical
F-LFK-370
(all unit serial numbers)
3 x Feet (foam)
3 x M20 x 200 mm Hex bolts
3 x M20 Hex Nyloc Nut
6 x M20 Plain Washer
3 x Nylon Cone Washer
Restraint
Harness Kit
F-RHK-02 units nos 0-212
F-RHK-03 units nos 213 onwards
3 x Seat Harnesses
Plus Fixings
Full Service Kit
For new frogs (unit no’s 213
onwards)
F-FSK-03-320
F-FSK-03-340
F-FSK-03-370
This kit combines the following Kits:
i. Critical Parts Kit
ii. Back-Up Lift-Eye Kit
iii. Landing Feet Kit
