CHAPTER 4
4-20
Chemical Toilet
Installed as standard equipment on your vessel is a self-contained
sanitation device known as a chemical toilet featuring an upper fresh
water tank and a lower deodorized tank. These two components can
be separated for waste disposal, cleaning and refi lling. The lower tank
contains a capacity gauge. Before each outing check the waste level
since it is illegal to dump waste within and extending out to the United
States territorial limit.
Refer to a typical system shown on the following page. For more
information, review the vendor manual supplied in the owner’s
information packet or visit their on-line location.
WASTE
TYPICAL CHEMICAL TOILET
FLUSHING BELLOWS
HOLD DOWN
BRACKET
LIFT & PULL FORWARD
TO REMOVE HEAD UNIT
DEODORIZED WASTE TANK
FRESH WATER TANK
