Equipment Operation
6-91
RegalVue Display
INSTALLING/REMOVING MEMORY CARD
As an option Regal Vue is in-
stalled as shown. Each unit is
outfi tted with a memory card
with predetermined geographi-
cal regions. Should the operator
want a different memory card
access to the Regal Vue panel is
outlined below.
1. The battery switch should be
turned to the “off ” position before starting to work behind the dash.
At the rear of the Regal Vue display (behind the dash) you will see
a small compartment with 2 allen head type fasteners. Remove both
fasteners with the panel cover to access the
memory card compartment.
2. Insert a fi ngernail or small slotted screw-
driver into the memory card end tab. Push up
to disengage the card. Next, pull down on the
card to remove it from the card slot.
FASTENERS
