Systems
4-3
WIRE COLOR CODES (CONTINUED)
Color Gauge Function
Blue 10 Cabin Light Main Feed
Blue/White 16 Transom Courtesy Lights
Gray 14-12 Bow, Navigation Lights
Gray/White 14-12 Mast Light (Fwd. Running)
Gray/Black 14-12 Mast Light (Anchor Light)
Red/Black 16 Windlass Up
Red/White 16 Windlass Down
Red 16 Gas Vapor Detector
Breaker To Dash
Feed Leads
Red 6-2/0 Main DC Panel Feed
Red 2 Feed, Starter, Battery
Red 4 Feed
Red 14 Bkr. Circuit Feed, Electronics
Yellow 16 Tank Monitor
Purple 16 Hour Meter, Ignition
Green 8 Bonding
Green 16 Tank Level Monitor
Pink 16 Fuel Tank Sender Feed
