Bellavista® B36XTCE-11 Gas Fireplace | 63
installation
FLUSH GLASS DOOR INSTALLATION
1. Line up slots on flush glass door with tabs in firebox. Hook slots on to tabs and lower door slowly (See Diagram 1).
2. Lower the flush door, then hook the 2 adjustable tension latches - close the latches to secure the flush door (See Diagram 2).
Diagram 1
Tabs in Firebox
Diagram 2
Adjustable Tension
Latch location
Note: To remove Flush Glass door reverse Steps 1 and 2.
