Corrigo E Heating manual, revision G Chapter 8 Configuration 32
8.12 Alarm configuration
Permits configuration of all alarms.
Select the appropriate alarm number (from the alarm list). The alarm text for the alarm will be
displayed and the alarm priority can be set: A-alarm, B-alarm, C-alarm or not active.
Alarm no (1-65): 1
Malfunction P1A-HS1
Æ
Malfunction P1A-HS1
Priority: B-alarm
Alarm list
Values in the Priority column show the factory set values.
Alarm text Pri Description
1 Malf. P1A-HS1 B Malfunction pump P1A-HS1
2 Malf. P1B-HS1 B Malfunction pump P1B-HS1
3 Malf. P1A-HS2 B Malfunction pump P1A-HS2
4 Malf. P1B-HS2 B Malfunction pump P1B-HS2
5 Malf. P1A-HS3 B Malfunction pump P1A-HS3
6 Malf. P1B-HS3 B Malfunction pump P1B-HS3
7 Malf. Frequenc B Malfunction frequency converter
8 Malf. P1-HWC A Malfunction pump P1-HWC
9 Malf. P1-VVB - Malfunction pump P1-VVB
10 Exp. vessel A Expansion vessel alarm
11 External alarm A External alarm
12 Boiler alarm A Boiler alarm
13 Deviation HS1 A Supply temp HS1 deviates too much from the
setpoint for too long.
14 Deviation HS2 A Supply temp HS2 deviates too much from the
setpoint for too long.
15 Deviation HS3 A Supply temp HS3 deviates too much from the
setpoint for too long.
16 Deviation HWC1 A Supply temp HWC1 deviates too much from the
setpoint for too long.
17 Deviation HWC2 A Supply temp HWC2 deviates too much from the
setpoint for too long.
18 Sensor error B Malfunction of a connected sensor
19 High HWC1 B HWC1 temperature too high
20 High HWC2 B HWC2 temperature too high
21 Boiler high B Boiler temperature too high
22 Boiler low B Boiler temperature too low
23 Pulse error volume B No pulses from water volume meter
24 Pulse error energy B No pulses from energy meter
25 High cold water B 24 hour cold water usage higher than limit
26 High energy B 24 hour energy usage higher than limit
